Omron F3SG-SR Series User Manual

F3SG-SR/PG
60
Arm/leg protection (Detection capability: 45-mm dia.)
List of Models and Response Times
Note: 1. The maximum speed of movement of a test rod up to which the detection capability is maintained is 2.0 m/s.
2. The response times of "Optical synchronization" are values when Scan Code is set at Code B. The response times for Code A are 1 ms
shorter than these values.
List of Models, Current Consumption and Weight
Note: 1. The net weight is the weight of an emitter and a receiver per set.
2. The gross weight is the weight of an emitter, a receiver, included accessories and a package.
Model
Number of
beams
Protective
height [mm]
Response time
(Optical synchronization) [ms]
Response time
(Wired
synchronization)
[ms]
ON to
OFF
OFF
(synchronized)
to ON
OFF (not
synchronized)
to ON
ON to
OFF
OFF to
ON
F3SG-4SR0240-45 F3SG-2SRB0240-45 6 240 8 40 140 10 50
F3SG-4SR0400-45 F3SG-2SRB0400-45 10 400 8 40 140 10 50
F3SG-4SR0560-45 F3SG-2SRB0560-45 14 560 8 40 140 10 50
F3SG-4SR0720-45 F3SG-2SRB0720-45 18 720 8 40 140 10 50
F3SG-4SR0880-45 F3SG-2SRB0880-45 22 880 8 40 140 10 50
F3SG-4SR1200-45 F3SG-2SRB1200-45 30 1200 8 40 140 10 50
F3SG-4SR1520-45 F3SG-2SRB1520-45 38 1520 8 40 140 10 50
Model
Number of
beams
Protective
height [mm]
Current consumption [mA] Weight [kg]
Emitter Receiver Net Gross
F3SG-4SRA0240-45 6 240 60 107 0.6 1.4
F3SG-SRB0240-45 6 240 52 95 0.6 1.4
F3SG-4SRA0400-45 10 400 71 116 1 1.9
F3SG-SRB0400-45 10 400 56 95 1 1.9
F3SG-4SRA0560-45 14 560 82 124 1.4 2.3
F3SG-SRB0560-45 14 560 60 96 1.4 2.3
F3SG-4SRA0720-45 18 720 93 133 1.8 2.8
F3SG-SRB0720-45 18 720 64 96 1.8 2.8
F3SG-4SRA0880-45 22 880 104 141 2.2 3.2
F3SG-SRB0880-45 22 880 68 97 2.2 3.2
F3SG-4SRA1200-45 30 1200 125 158 3.1 4.2
F3SG-SRB1200-45 30 1200 75 98 3.1 4.2
F3SG-4SRA1520-45 38 1520 147 175 3.9 5.3
F3SG-SRB1520-45 38 1520 83 99 3.9 5.3
