17
Easy on-site monitoringEasy remote monitoring
The Bluetooth communication unit allows
you to monitor information about device
stoppages on mobile devices.
Various devices can be
connected via IO-Link.*
1
Process data Requirements
Service data
System configuration example
・Auxiliary output status *
2
・Muting input status
・Sequence error information
・Unstable state information (each ch)
・Power voltage information
・OSSD output status
Android™ 7.0 or higher
Windows
®
10
SD Manager 3
Mobile APP
Startup screen Error log screen
Light level monitoring
・Reset/EDM/override
input status
・Instantaneous block
information (each ch)
・Light curtain/Intelligent
Tap lockout information
・Light curtain information
・
Light intensity information (1 byte : 0-255)
・Light curtain settings
・
Light curtain internal status information
・Intelligent Tap power-on
time information
・Intelligent Tap information
・Error log (4 errors)
*1. Refer to the IO-Link Series Catalog (Cat. No. Y229) for details. *2. Auxiliary output can be set using the SD Manager 3.
Note : Screen images for
illustration purposes only.
Safety output
F39-SGIT-IL3 Intelligent Tap
F39-SGBT Bluetooth Communication Unit
SD Manager 3
Mobile APP
USB Type - C™
SD Manager 3
Note : Screen images for
illustration purposes only.
No PC
required
on site
ICT facilitates more detailed data monitoring
There is no need for a PC on site to check the light curtain status.
Quick maintenance through ICTMaintenance
