Omron F3SG-SR Series User Manual

F3SG-SR/PG
55
Ratings and
Specifications
List of Models/Response Time/
Current Consumption/Weight
List of Models/Response Time/Current Consumption/Weight
F3SG-SR
Finger protection (Detection capability: 14-mm dia.)
List of Models and Response Times
Note: 1. The maximum speed of movement of a test rod up to which the detection capability is maintained is 2.0 m/s.
2. The response times of "Optical synchronization" are values when Scan Code is set at Code B. The response times for Code A are 1 ms
shorter than these values.
Model
Number of
beams
Protective
height [mm]
Response time
(Optical synchronization) [ms]
Response time
(Wired
synchronization)
[ms]
ON to
OFF
OFF
(synchronized)
to ON
OFF (not
synchronized)
to ON
ON to
OFF
OFF to
ON
F3SG-4SR  0160-14 F3SG-2SRB0160-14 15 160 8 40 140 10 50
F3SG-4SR  0200-14-F --- 19 200 8 40 140 10 50
F3SG-4SR  0240-14 F3SG-2SRB0240-14 23 240 8 40 140 10 50
F3SG-4SR  0280-14-F --- 27 280 8 40 140 10 50
F3SG-4SR  0320-14 F3SG-2SRB0320-14 31 320 8 40 140 10 50
F3SG-4SR  0360-14-F --- 35 360 8 40 140 10 50
F3SG-4SR  0400-14 F3SG-2SRB0400-14 39 400 8 40 140 10 50
F3SG-4SR  0440-14-F --- 43 440 13 65 165 17 85
F3SG-4SR  0480-14 F3SG-2SRB0480-14 47 480 13 65 165 17 85
F3SG-4SR  0520-14-F --- 51 520 13 65 165 17 85
F3SG-4SR  0560-14 F3SG-2SRB0560-14 55 560 13 65 165 17 85
F3SG-4SR  0600-14-F --- 59 600 13 65 165 17 85
F3SG-4SR  0640-14 F3SG-2SRB0640-14 63 640 13 65 165 17 85
F3SG-4SR  0680-14-F --- 67 680 13 65 165 17 85
F3SG-4SR  0720-14-F --- 71 720 13 65 165 17 85
F3SG-4SR  0760-14-F --- 75 760 13 65 165 17 85
F3SG-4SR  0800-14 F3SG-2SRB0800-14 79 800 13 65 165 17 85
F3SG-4SR  0840-14-F --- 83 840 13 65 165 17 85
F3SG-4SR  0880-14-F --- 87 880 13 65 165 17 85
F3SG-4SR  0920-14-F --- 91 920 13 65 165 17 85
F3SG-4SR  0960-14-F --- 95 960 13 65 165 17 85
F3SG-4SR  1000-14 F3SG-2SRB1000-14 99 1000 13 65 165 17 85
F3SG-4SR  1200-14 F3SG-2SRB1200-14 119 1200 13 65 165 17 85
F3SG-4SR  1400-14 F3SG-2SRB1400-14 139 1400 13 65 165 17 85
F3SG-4SR  1600-14 F3SG-2SRB1600-14 159 1600 18 90 190 21 105
F3SG-4SR  1800-14 F3SG-2SRB1800-14 179 1800 18 90 190 21 105
F3SG-4SR  2000-14 F3SG-2SRB2000-14 199 2000 18 90 190 21 105
