Model Number Legend
Safety Light Curtain F3SG-SR
Note: 1. The purpose of this model number legend is to provide understanding of the meaning of specifications from the model number.
Models are not available for all combinations of code numbers.
See Ordering Information on page 34 for details.
2. The side-mount brackets (intermediate brackets) are included with the safety light curtain.
3. Connection cables are not included with the safety light curtain. Order cables sold separately.
Safety Multi-Light Beam F3SG-PG
Note: 1. The purpose of this model number legend is to provide understanding of the meaning of specifications from the model number.
Models are not available for all combinations of code numbers.
See Ordering Information on page 36 for details.
2. The side-mount brackets (intermediate brackets) are included with the safety multi-light beam.
3. Connection cables are not included with the safety multi-light beam. Order cables sold separately.
No. Classification Code Meaning Remarks
(1) Type of ESPE 4 Type 4
(2) Function
A Advanced
B Standard
(3) Protective height
0160 - 2000 Protective height for finger protection (mm)
0160 - 2480 Protective height for hand protection (mm)
0240 - 1520 Protective height for arm/leg protection (mm)
0280 - 0920 Protective height for body protection (mm)
(4)
Detection
capability
14
Finger protection (Detection capability: 14-mm dia.)
25 Hand protection (Detection capability: 25-mm dia.)
45
Arm/leg protection (Detection capability: 45-mm dia.)
85 Body protection (Detection capability: 85-mm dia.)
(5) Option 1
Blank Set of emitter and receiver
L Emitter
D Receiver
(6) Option 2
Blank
F Flexible height model
Finger protection and hand protection:
Protective heights are available in increments
of 40 mm up to 1 m
No. Classification Code Meaning Remarks
(1) Type of ESPE 4 Type 4
(2) Function A Advanced
(3) Protective height
0580
Protective height (mm)
0880
0980
1280
(4)
Number of beams/
beam gap
2 2 beams/500 mm Protective height: 580 mm
3 3 beams/400 mm Protective height: 880 mm
4 4 beams/300 or 400 mm Protective height: 980 or 1,280 mm
(5) Application
A Perimeter access guarding
L Perimeter guarding long range
C Perimeter guarding deflect mirror
(6) Option 1
Blank
Set of emitter and receiver or set of emitter/receiver
and passive mirror
L Emitter
D Receiver
LD Emitter/receiver Perimeter guarding deflect mirror only
M Passive mirror Perimeter guarding deflect mirror only
(7) Option 2 Blank
F3SG-4SR @ @@@@ - @@ - @ - @
(1) (2) (3) (4) (5) (6)
F3SG-4PG A @@@@ - @ @ - @ - @
(1) (2) (3) (4) (5) (7)(6)
