19
Ignoring interrupted beams : Reduced Resolution
Built-in standard safety functions
Reduced Resolution changes
the detection capability of the light curtain
Even when objects (with a size of 1 to 3 interrupted beams) are present discontinuously,
this function ignores them and keeps the safety outputs ON. This helps maintain productivity.
Example : Arm and body protection
Monitoring
I/O setting Operation state change
Safety function setting
Safety output is kept ON even
if worker’s finger and an object
interrupt 2 beams because
they are allowed to enter.
When worker’s arm or body,
which interrupts 3 beams is
detected, safety output is
turned OFF.
Note : Ensure that the desired safety distance is maintained.
Incident /Ambient
Light Level Information
Interlock / External
Device Monitoring
Response Time
Adjustment
Teach-in Input Operating Range
Selection
External Test Input
Fixed Blanking Floating Blanking Muting/Override Warning Zone
To Next Page
