Cascading Cable for Extended (F39-JGR3W, sold separately)
(two cables per set, one for emitter and one for receiver)
Emitter Cascading Cable for Extended
Receiver Cascading Cable for Extended
Side-by-side Cascading Cable (F39-JGR12L, sold separately)
(two cables per set, one for emitter and one for receiver)
Side-by-side Cascading Cable for Emitter
Side-by-side Cascading Cable for Receiver
Conversion Cable
F3SJ-B/A Conversion Cable for Emitter (F39-JGR3K-SJ-L, sold separately)
Set model name Emitter cable (Gray) Receiver cable (Black) Length
F39-JGR3W F39-JGR3W-L F39-JGR3W-D 0.3 m
Set model name Emitter cable (Gray) Receiver cable (Black) Length
F39-JGR12L F39-JGR12L-L F39-JGR12L-D 12 cm
14.9 dia.
Oil-resistant PVC-insulated round cable, dia. 6
minimum bending radius R5, 5-wire
(Cross section of conductor: 0.2 mm
2
/
insulator diameter: dia. 1.1 mm)
2-M2.5 screw
31.6
18.5
16.4
300
40.7
M12 IP67 Connector
Connector
14.9 dia.
Oil-resistant PVC-insulated round cable, dia. 6
minimum bending radius R5, 8-wire
(Cross section of conductor: 0.2 mm
2
/
insulator diameter: dia. 1.1 mm)
2-M2.5 screw
18.5
M12 IP67 Connector
Connector
16.4
300
40.7
31.6
2-M2.5 screw
Oil-resistant PVC-insulated round cable, dia. 6
minimum bending radius R5, 5-wire
(Cross section of conductor: 0.2 mm
2
/insulator diameter: dia. 1.1 mm)
120
18.5
31.6
2-M2.5 screw
31.6
BTM side TOP side
18.5
16.4 16.4
Connector
Connector
2-M2.5 screw
Oil-resistant PVC-insulated round cable, dia. 6
minimum bending radius R5, 8-wire
(Cross section of conductor: 0.2 mm
2
/insulator diameter: dia. 1.1 mm)
120
18.5
31.6
2-M2.5 screw
31.6
18.5
16.4 16.4
Connector
Connector
BTM side TOP side
Connector
M12 IP67 connector, 8-wire
14.9 dia.
2-M2.5 screw
31.6
18.5
44.7
300
16.4
Oil-resistant PVC-insulated round cable, dia. 6
minimum bending radius R5
(Cross section of conductor
: 0.2 mm
2
/insulator diameter: dia. 1.1 mm)
