Omron F3SG-SR Series User Manual

F3SG-SR/PG
93
Dimensions
F3SJ-B/A Conversion Cable for Receiver (F39-JGR3K-SJ-D, sold separately)
F3SG-RE Conversion Cable for Emitter (F39-JGR3K-RE-L, sold separately)
F3SG-RE Conversion Cable for Receiver (F39-JGR3K-RE-D, sold separately)
MS48 Conversion Cable for Emitter (F39-JGR3K-MS-L, sold separately)
MS48 Conversion Cable for Receiver (F39-JGR3K-MS-D, sold separately)
Emitter cable (Gray) Receiver cable (Black) Length
F39-JGR3K-SJ-L F39-JGR3K-SJ-D 0.3 m
Emitter cable (Gray) Receiver cable (Black) Length
F39-JGR3K-RE-L F39-JGR3K-RE-D 0.3 m
Emitter cable (Gray) Receiver cable (Black) Length
F39-JGR3K-MS-L F39-JGR3K-MS-D 0.3 m
Connector
M12 IP67 connector, 8-wire
14.9 dia.
2-M2.5 screw
31.6
18.5
44.7
300
16.4
Oil-resistant PVC-insulated round cable, dia. 6
minimum bending radius R5
(Cross section of conductor
: 0.2 mm
2
/insulator diameter: dia. 1.1 mm)
Connector
M12 IP67 connector, 4-wire
Oil-resistant PVC-insulated round cable, dia. 6
minimum bending radius R5
(Cross section of conductor: 0.2 mm
2
/insulator diameter: dia. 1.1 mm)
44.7
14.9 dia.
300
31.6
18.5
2-M2.5 screw
16.4
Connector
M12 IP67 connector, 4-wire
Oil-resistant PVC-insulated round cable, dia. 6
minimum bending radius R5
(Cross section of conductor: 0.2 mm
2
/insulator diameter: dia. 1.1 mm)
44.7
14.9 dia.
300
31.6
18.5
2-M2.5 screw
16.4
Connector
M12 IP67 connector, 5-wire
Oil-resistant PVC-insulated round cable, dia. 6
minimum bending radius R5
(Cross section of conductor: 0.2 mm
2
/insulator diameter: dia. 1.1 mm)
44.7
14.9 dia.
300
31.6
18.5
2-M2.5 screw
16.4
Connector
M12 IP67 connector, 8-wire
14.9 dia.
2-M2.5 screw
31.6
18.5
44.7
300
16.4
Oil-resistant PVC-insulated round cable, dia. 6
minimum bending radius R5
(Cross section of conductor
: 0.2 mm
2
/insulator diameter: dia. 1.1 mm)
