Omron F3SG-SR Series User Manual

F3SG-SR/PG
57
List of Models/Response Time/
Current Consumption/Weight
Hand protection (Detection capability: 25-mm dia.)
List of Models and Response Times
Note: 1. The maximum speed of movement of a test rod up to which the detection capability is maintained is 2.0 m/s.
2. The response times of "Optical synchronization" are values when Scan Code is set at Code B. The response times for Code A are 1 ms
shorter than these values.
Model
Number of
beams
Protective
height [mm]
Response time
(Optical synchronization) [ms]
Response time
(Wired
synchronization)
[ms]
ON to
OFF
OFF
(synchronized)
to ON
OFF (not
synchronized)
to ON
ON to
OFF
OFF to
ON
F3SG-4SR  0160-25 F3SG-2SRB0160-25 8 160 8 40 140 10 50
F3SG-4SR  0200-25-F --- 10 200 8 40 140 10 50
F3SG-4SR  0240-25 F3SG-2SRB0240-25 12 240 8 40 140 10 50
F3SG-4SR  0280-25-F --- 14 280 8 40 140 10 50
F3SG-4SR  0320-25 F3SG-2SRB0320-25 16 320 8 40 140 10 50
F3SG-4SR  0360-25-F --- 18 360 8 40 140 10 50
F3SG-4SR  0400-25 F3SG-2SRB0400-25 20 400 8 40 140 10 50
F3SG-4SR  0440-25-F --- 22 440 8 40 140 10 50
F3SG-4SR  0480-25 F3SG-2SRB0480-25 24 480 8 40 140 10 50
F3SG-4SR  0520-25-F --- 26 520 8 40 140 10 50
F3SG-4SR  0560-25 F3SG-2SRB0560-25 28 560 8 40 140 10 50
F3SG-4SR  0600-25-F --- 30 600 8 40 140 10 50
F3SG-4SR  0640-25 F3SG-2SRB0640-25 32 640 8 40 140 10 50
F3SG-4SR  0680-25-F --- 34 680 8 40 140 10 50
F3SG-4SR  0720-25 F3SG-2SRB0720-25 36 720 8 40 140 10 50
F3SG-4SR  0760-25-F --- 38 760 8 40 140 10 50
F3SG-4SR  0800-25 F3SG-2SRB0800-25 40 800 8 40 140 10 50
F3SG-4SR  0840-25-F --- 42 840 13 65 165 17 85
F3SG-4SR  0880-25 F3SG-2SRB0880-25 44 880 13 65 165 17 85
F3SG-4SR  0920-25-F --- 46 920 13 65 165 17 85
F3SG-4SR  0960-25 F3SG-2SRB0960-25 48 960 13 65 165 17 85
F3SG-4SR  1000-25-F --- 50 1000 13 65 165 17 85
F3SG-4SR  1040-25 F3SG-2SRB1040-25 52 1040 13 65 165 17 85
F3SG-4SR  1120-25 F3SG-2SRB1120-25 56 1120 13 65 165 17 85
F3SG-4SR  1200-25 F3SG-2SRB1200-25 60 1200 13 65 165 17 85
F3SG-4SR  1280-25 F3SG-2SRB1280-25 64 1280 13 65 165 17 85
F3SG-4SR  1360-25 F3SG-2SRB1360-25 68 1360 13 65 165 17 85
F3SG-4SR  1440-25 F3SG-2SRB1440-25 72 1440 13 65 165 17 85
F3SG-4SR  1520-25 F3SG-2SRB1520-25 76 1520 13 65 165 17 85
F3SG-4SR  1600-25 F3SG-2SRB1600-25 80 1600 13 65 165 17 85
F3SG-4SR  1680-25 F3SG-2SRB1680-25 84 1680 13 65 165 17 85
F3SG-4SR  1760-25 F3SG-2SRB1760-25 88 1760 13 65 165 17 85
F3SG-4SR  1840-25 F3SG-2SRB1840-25 92 1840 13 65 165 17 85
F3SG-4SR  1920-25 F3SG-2SRB1920-25 96 1920 13 65 165 17 85
F3SG-4SR  2080-25 F3SG-2SRB2080-25 104 2080 13 65 165 17 85
F3SG-4SR  2280-25 F3SG-2SRB2280-25 114 2280 13 65 165 17 85
F3SG-4SR  2480-25 F3SG-2SRB2480-25 124 2480 13 65 165 17 85
