F3SG-SR/PG
62
Legislation and Standards
1.
The F3SG-SR does not receive type approval provided by Article 44-2 of the Industrial Safety and Health Act of Japan. When using the F3SG-SR in Japan
as a "safety system for pressing or shearing machines" prescribed in Article 42 of that law, the machine control system must receive type approval.
2.
The F3SG-SR is electro-sensitive protective equipment (ESPE) in accordance with European Union (EU) Machinery Directive Index Annex V, Item 2.
3. EU Declaration of Conformity
OMRON declares that the F3SG-SR is in conformity with the requirements of the
following EU Directives:
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EU
4. Confor
ming Standards
(1) Europ
ean standards
EN61496-1 (Type 4 and Type 2 ESPE), EN 61496-2 (Type 4 and Type 2 AOPD), EN61508-1 through -4 (SIL 3 for Type 4 and SIL 1 for Type 2),
EN ISO 13849-1:2015 (PL e, Category 4 for Type 4 and PL c, Category 2 for Type 2)
(2) International standards
IEC61496-1 (Type 4 and Type 2 ESPE), IEC61496-2 (Type 4 and Type 2 AOPD), IEC61508-1 through -4 (SIL 3 for Type 4 and SIL 1 for Type 2),
ISO 13849-1:2015 (PL e, Category 4 for Type 4 and PL c, Category 2 for Type 2)
(3) JIS standards
JIS B 9704-1 (Type 4 and Type 2 ESPE), JIS B 9704-2 (Type 4 and Type 2 A
OPD)
(4) North American standards
UL61496-1 (Type 4 and Type 2 ESPE), UL61496-2 (Type 4 and Type 2 AOPD), UL508, UL1
998,
CAN/CSA C22.2 No.14, CAN/CSA C22.2 No.0.8
(5) Chinese standards
GB/T 4584 (Specification of active opto-electr
onic protective devices for pr
esses)
(Models: F3SG-4SR
-14/-25 in the case of the ON to OFF response time not exceeding 20 ms max.)
The following configurations of the F3SG-SR are compliant with GB/T 4584.
C
onfigurations using the F3SG-SR with detection capability of 14-mm or 25-mm d
ia. and 20 ms max. of the ON to OFF response time
* Refer to User
's Manual (Man.No.Z405) for more information on the response time for the F3SG-SR in cascade connection.
Note: The F3SG-SR's with detection capability of 45-mm and 85-mm dia. are not compliant with GB/T 4584. Refer to Ratings and
Specifications on page
49 for more information on the ratings and specifications by mod
el.
5. Third-Party Certifications
(1) TÜ
V SÜD
• EC Type-Examination certificate:
EU Machinery Directive, Type 4 and Type 2 ESPE (EN61496-1), Type 4 and Type 2 AOPD (EN 6
1496-2)
• Certificate:
Type 4 and Type 2 ESPE (EN61496-1), Type 4 and Type 2 AOPD (EN61496-2),
EN 61508-1 through
-4 (SIL 3 for Type 4 and SIL 1 for
Type 2), EN ISO 13849-1:2015 (PL e, Category 4 for Type 4, and PL c, Category 2 for Type 2)
(2) UL
• UL Listing:
Type 4 and Type 2 ESPE (UL61496-1), Type 4 and Type 2 AOPD (UL61496-2), UL508, UL1998, CAN/CSA C22.2 No.14, CAN/CSA C22.2 No.0.8
(3) China National Casting and Forging Machines Quality Supervision and Inspection Center
• Certificate:
GB/T 4584 (Specification of active opto-electron
ic protec
tive devices for presses)
(Models: F3SG-4SR
-14/-25 in the case of the ON to OFF response time not exceeding 20 ms max.)
6. Other Standards
The F3
SG-SR/PG is designed according to the standards listed below
. To make sure that the final system complies with the following standards
and regulations, you are asked to design and use it in accordance with all other related standards, laws, and regulations. If you have any
questions, consult with specialized organizations such as the body responsible for prescribing and/or enforcing machinery safety regulations in
the location where the equipment is to be used.
• European Standards: EN415-4, EN691-1, EN692, EN693, IEC 62046
• U.S. Occupational Safety and Health Standards: OSHA 29 CFR 1910.212
• U.S. Occupational Safety and Health Standards: OSHA 29 CFR 1910.217
• American National Standards: ANSI B11.1 to B11.19
• American National Standards: ANSI/RIA R15.06
• Canadian Standards Association CSA Z142, Z432, Z434
• SEMI Standards SEMI S2
• Japan Ministry of Health, Labour and Welfare "Guidelines for C
omprehensive
Safety Standards of Machinery", Standard Bureau's
Notification No. 0731001 dated July 31, 2007.rms and Conditions Agreement
• Chinese National Standards: GB17120, GB27607
7. Meaning of mark according to EU WEEE Directi
ve
D
ispose in accordance with applicable regulations.
8. Regions where F
39-SGBT can be used
For
the regions where the F39-SGBT can be used, refer to the following instruction
manuals of the F39-SGBT.
Detection capability Protective height
Number of
beams
Configuration
Synchronization
method
Response Time
Adjustment
ON to OFF
response time
14-mm dia. 160 to 2000 mm - Single Optical Normal 18 ms max.
14-mm dia. 160 to 1400 mm - Single Wired Normal 17 ms max.
25-mm dia. 160 to 2480 mm - Single Optical/Wired Normal 17 ms max.
Combination of 14-mm 25-mm dia.
In cascade conne
ction
- 25
5 max. Cascaded Optical Normal 18 ms max. *
Combination of 14-mm 25-mm dia.
In cascade connection
- 14
0 max. Cascaded Wired Normal 15 ms max. *
Document Title No.
F39-SGBT Instruction Sheet 4615743-0
F39-SGBT Regulations and Standards 4615744-8
