Omron F3SG-SR Series User Manual

F3SG-SR/PG
61
List of Models/Response Time/
Current Consumption/Weight
Body protection (Detection capability: 85-mm dia.)
List of Models and Response Times
Note: 1. The maximum speed of movement of a test rod up to which the detection capability is maintained is 2.0 m/s.
2. The response times of "Optical synchronization" are values when Scan Code is set at Code B. The response times for Code A are 1 ms
shorter than these values.
List of Models, Current Consumption and Weight
Note: 1. The net weight is the weight of an emitter and a receiver per set.
2. The gross weight is the weight of an emitter, a receiver, included accessories and a package.
Model
Number of
beams
Protective
height
[mm]
Response time
(Optical synchronization) [ms]
Response time
(Wired
synchronization)
[ms]
ON to
OFF
OFF
(synchronized)
to ON
OFF (not
synchronized)
to ON
ON to
OFF
OFF to
ON
F3SG-4SR0280-85 F3SG-2SRB0280-85 4 280 8 40 140 10 50
F3SG-4SR0440-85 F3SG-2SRB0440-85 6 440 8 40 140 10 50
F3SG-4SR0600-85 F3SG-2SRB0600-85 8 600 8 40 140 10 50
F3SG-4SR0760-85 F3SG-2SRB0760-85 10 760 8 40 140 10 50
F3SG-4SR0920-85 F3SG-2SRB0920-85 12 920 8 40 140 10 50
Model
Number of
beams
Protective
height [mm]
Current consumption [mA] Weight [kg]
Emitter Receiver Net Gross
F3SG-4SRA0280-85 4 280 63 111 0.7 1.5
F3SG-SRB0280-85 4 280 50 95 0.7 1.5
F3SG-4SRA0440-85 6 440 72 120 1.1 2
F3SG-SRB0440-85 6 440 52 95 1.1 2
F3SG-4SRA0600-85 8 600 81 128 1.5 2.5
F3SG-SRB0600-85 8 600 54 96 1.5 2.5
F3SG-4SRA0760-85 10 760 91 136 1.9 2.9
F3SG-SRB0760-85 10 760 56 96 1.9 2.9
F3SG-4SRA0920-85 12 920 100 145 2.3 3.4
F3SG-SRB0920-85 12 920 58 96 2.3 3.4
