F3SG-SR/PG
53
Ratings and
Specifications
Intelligent Tap F39-SGIT-IL3
Model F39-SGIT-IL3
Applicable sensor F3SG-SR Series
Performance
Response time
Output ON to OFF and OFF to ON: 44 ms max. each *
*
The response time is the time interval between the changes of the states of the sensor OSSD's and the DO (pin 2).
Startup waiting time 3 s max.
Electrical
Power supply voltage (Vs)
Supplied from external power source: SELV/PELV 24 VDC±20% (ripple p-p 10% max.)
USB bus powered: 5 VDC
Current consumption 85 mA max. (When connecting 24 VDC power supply and IO-Link Master)
Safety outputs (OSSD)
/Auxiliary output
Refer to the ratings and specifications of the F3SG-SR. The safety outputs and auxiliary output of the
Intelligent Tap are directly connected to those of the F3SG-SR.
Digital output for pin 2 (IO-Link)
*
One PNP transistor output
Load current: 100 mA max., Residual voltage: 2 V max., Leakage current: 1 mA max.
The DO is in the OFF state when the safety outputs are in the ON state. The DO is in the ON state when the
safety outputs are in the OFF state. (Regardless of the PNP/NPN setting of the F3SG-SR)
* For the DO (pin 2) of CN3
Input voltage
RESET, EDM
PNP
ON voltage: Vs-3 V to Vs (short circuit current: approx. 9.5 mA) *2
OFF voltage: 0 V to 1/2 Vs, or open (short circuit current: approx. 13.0 mA) *2
NPN
ON voltage: 0 to 3 V (short circuit current: approx. 13.0 mA)
OFF voltage: 1/2 Vs to Vs, or open (short circuit current: approx. 9.5 mA) *2
MUTE A/B,
PRE-RESET,
PSDI *1
PNP
ON voltage: Vs-3 V to Vs (short circuit current: approx. 4.5 mA) *2
OFF voltage: 0 V to 1/2 Vs, or open (short circuit current: approx. 7.0 mA) *2
NPN
ON voltage: 0 to 3 V (short circuit current: approx. 7.0 mA)
OFF voltage: 1/2 Vs to Vs, or open (short circuit current: approx. 4.5 mA) *2
*1. PSDI is only available for F3SG-SR.
*2. The Vs indicates a supply voltage value in your environment.
Overvoltage category
(IEC 60664-1)
II
Protective circuit Output short-circuit protection, Output reverse polarity protection
Insulation resistance 20 MΩ or higher (500 VDC megger)
Dielectric strength 1,000 VAC, 50/60 Hz (1 min)
Functional Maintenance Information
Error Log
Power-ON Time
Environmental
Ambient
temperature
Operating -30 to 55 °C (non-icing)
Storage -30 to 70 °C
Ambient
humidity
Operating 35% to 85% (non-condensing)
Storage 35% to 85%
Degree of protection (IEC 60529) IP65, IP67 and IP67G (Covers and cables connected with the Intelligent Tap.)
Vibration resistance (IEC 61496-1)
10 to 55 Hz, Multiple amplitude of 0.7 mm, 20 sweeps for all 3 axes
Shock resistance (IEC 61496-1) 100 m/s
2
, 1000 shocks for all 3 axes
Pollution degree (IEC 60664-1) 3
Connections
To sensors, control box and IO-
Link
M12 connectors: 8-pin (CN1: receiver and CN2: control box) and 5-pin (CN3: IO-Link and CN4: emitter),
IP67 and IP67G (JIS C 0920 Annex 1) * rated when mated.
* The F3SG-SR meets the degree of protection when the root cable of the F3SG-SR is correctly connected
with the F3SG-SR.
Connection USB Type-C
Cable extension
20 m max. between IO-Link Master and Intelligent Tap, 4 m max.* between PC and Intelligent Tap via USB
cable
* It is not guaranteed that the Intelligent Tap is connectable to any PC or USB cable. Verify the connection
with the USB cable you use.
IO-Link
communications
IO-Link version Version 1.1
Baud rate COM3: 230.4 kbps
Data length PD: 4 bytes, OD: 32 bytes (M-sequence type: TYPE_2_V)
Minimum cycle time 12 ms
Material PBT resin
Weight F39-SGIT-IL3: 180 g (when packaged), F39-LITF1: 50 g (when packaged)
Included accessories
Instruction Sheet and M12 Connector Cover (2 pcs)
