F3SG-SR/PG
77
Input/Output Circuit
Input Circuit Diagram by Function
The input circuit diagrams of by function are shown below.
Test Input
Operating Range Select Input
RESET/EDM, MUTE A/B
<Light emission stops when connected to 0 V>
0 VDC
<Light emission stops when connected to 24 VDC>
0 VDC
Short circuit
current
Approx. 5.0 mA
+24 VDC +24 VDC
Short circuit
current
Approx. 6.0 mA
Emitter
main circuit
Emitter
main circuit
<Short>
Emitter
main circuit
+24 VDC
0 VDC
5 V
Short circuit
current
Approx. 4.2 mA
<Long>
+24 VDC
0 VDC
5 V
Emitter
main circuit
Short circuit
current
Approx. 4.2 mA
Receiver
main circuit
+24 VDC
0 VDC
Short circuit
current *2
<NPN><PNP>
Receiver
main circuit
+24 VDC
0 VDC
Short circuit
current
*
1
*
1. Short circuit current: approx. 9.5 mA (RESET/EDM),
approx. 4.5 mA (MUTE A/B)
*
2. Short circuit current: approx. 13.0 mA (RESET/EDM),
approx. 7.0 mA (MUTE A/B)
