Omron F3SG-SR Series User Manual

25
●❹●❺
Select an option.*
STEP 1 Choose a safety light curtain
* Representative models are listed. For other models, refer to page 34 and following.
Hand Protection
Finger Protection and Hand Protection only
Protective height
(mm)
Number of
beams
●❸
160 8 □□□□＝0160
240 12
□□□□＝0240
320 16
□□□□＝0320
400 20
□□□□＝0400
480 24
□□□□＝0480
560 28
□□□□＝0560
640 32
□□□□＝0640
720 36
□□□□＝0720
800 40
□□□□＝0800
880 44
□□□□＝0880
960 48
□□□□＝0960
1040 52
□□□□＝1040
1120 56
□□□□＝1120
1200 60
□□□□＝1200
1280 64
□□□□＝1280
1360 68
□□□□＝1360
1440 72
□□□□＝1440
1520 76
□□□□＝1520
1600 80
□□□□＝1600
1680 84
□□□□＝1680
1760 88
□□□□＝1760
1840 92
□□□□＝1840
1920 96
□□□□＝1920
2080 104
□□□□＝2080
2280 114
□□□□＝2280
2480 124
□□□□＝2480
Type
●❹
Set of emitter
and receiver
Blank
Emitter
□＝
L
Receiver
□＝
D
Type
●❺
-
Blank
Flexible Height Model
<Protective heights available
in increments of 40 mm>
□＝
F
