Protection at machine openings :
Safety Light Curtain F3SG-SR
Protection around perimeters of equipment :
Safety Multi-Light Beam F3SG-PG
Series
Advanced/Standard Perimeter Access Guarding
Perimeter Guarding Long Range
Perimeter Guarding Deflect Mirror
Application
Finger Protection
Finger Protection
Application
Hand Protection Hand Protection
Arm/Leg Protection Arm/Leg Protection
Body Protection Body Protection
Specification
Detection capability 14-mm dia. 25-mm dia. 45-mm dia. 85-mm dia.
---
Detection capability
Specification
Beam gap 10 mm 20 mm 40 mm 80 mm 300 mm/400 mm/500 mm Beam gap
Max. operating range 10 m 20 m 20 m 20 m 20 m 70 m 6 to 10 m
*2
Max. operating range
Protective height 160 to 2,000 mm 160 to 2,480 mm 240 to 1,520 mm 280 to 920 mm 580 to 1,280 mm Protective height
Number of beams 15 to 199 8 to 124 6 to 38 4 to 12 2 to 4 Number of beams
Degree of protection IP65, IP67, and IP67G IP65 and IP67 Degree of protection
Feature
Mutual interference
prevention
(No settings required for wired synchronization)
(No settings required for wired synchronization)
Mutual interference
prevention
Feature
PNP/NPN Selection PNP/NPN Selection
External Test
Not supported
External Test
Interlock
/
/
Interlock
Reset Reset
Pre-Reset
/
/
Pre-Reset
PSDI Not supported PSDI
External Device Monitoring (EDM)
/
/
External Device Monitoring (EDM)
Auxiliary Output Auxiliary Output
Muting Muting
Blanking
/
Not supported Blanking
Reduced Resolution
Not supported
Reduced Resolution
Warning Zone Not supported Warning Zone
Operating Range Selection
/
/
/
/
Not supported
Operating Range Selection
Response Time Adjustment Response Time Adjustment
Area Beam Indicator (ABI)
* Advanced models only
Area Beam Indicator (ABI)
Designated Beam Output Designated Beam Output
Connection/
wiring
Cascade connection Available Available Available Available
Not available Not available Not available Cascade connection
Connection/
wiring
Reduced wiring system
*1
Available Available Available Available Available Available Available Reduced wiring system
*1
Accessory
Laser Alignment Pointer Available Available Available Available
Available Available Available
*3
Laser Alignment Pointer
Accessory
Lamp Available Available Available Available Available Available Available
*3
Lamp
IP69K model
Available Available Not available Not available Available Not available Not available
IP69K model
Setting by DIP switch on Intelligent Tap Setting by configuration tool SD Manager 3 Setting by wiring
Setting by end cap
*
1. The reduced wiring system includes the Y-joint plug/socket connector, reset switch connector, and muting sensor connection box (available soon).
*2. Varies depending on the model.
*3. Cannot be mounted on the passive mirror.
Available soon
Available soon
Available soon
