Omron F3SG-SR Series User Manual

F3SG-SR/PG
36
Arm/Leg protection (Detection capability: 45-mm dia.)
Body (Detection capability: 85-mm dia.)
Safety Multi-Light Beam
* Emitters and receivers (or emitter/receivers and passive mirrors) are available separately. For detail, contact your Omron representative.
Example 1) Emitter: F3SG-4PGA0580-2A-L, receiver: F3SG-4PGA0580-2A-D
Example 2) Emitter/receiver: F3SG-4PGA0880-3C-LD, passive mirror: F3SG-4PGA0880-3C-M
Perimeter access guarding (Beam gap: 300 to 500 mm)
Perimeter guarding long range (Beam gap: 300 to 500 mm)
Perimeter guarding deflect mirror (Beam gap: 300 to 500 mm)
Number of beams
Protective height
(mm)
Advanced Standard
Model Model
6 240 F3SG-4SRA0240-45 F3SG-4SRB0240-45
10 400 F3SG-4SRA0400-45 F3SG-4SRB0400-45
14 560 F3SG-4SRA0560-45 F3SG-4SRB0560-45
18 720 F3SG-4SRA0720-45 F3SG-4SRB0720-45
22 880 F3SG-4SRA0880-45 F3SG-4SRB0880-45
30 1,200 F3SG-4SRA1200-45 F3SG-4SRB1200-45
38 1,520 F3SG-4SRA1520-45 F3SG-4SRB1520-45
Number of beams
Protective height
(mm)
Advanced Standard
Model Model
4 280 F3SG-4SRA0280-85 F3SG-4SRB0280-85
6 440 F3SG-4SRA0440-85 F3SG-4SRB0440-85
8 600 F3SG-4SRA0600-85 F3SG-4SRB0600-85
10 760 F3SG-4SRA0760-85 F3SG-4SRB0760-85
12 920 F3SG-4SRA0920-85 F3SG-4SRB0920-85
Number of beams
Protective height
(mm)
Advanced
Model
2 580 F3SG-4PGA0580-2A
3 880 F3SG-4PGA0880-3A
4 980 F3SG-4PGA0980-4A
4 1,280 F3SG-4PGA1280-4A
Number of beams
Protective height
(mm)
Advanced
Model
2 580 F3SG-4PGA0580-2L
3 880 F3SG-4PGA0880-3L
4 980 F3SG-4PGA0980-4L
4 1,280 F3SG-4PGA1280-4L
Number of beams
Protective height
(mm)
Advanced
Model
2 580 F3SG-4PGA0580-2C
3 880 F3SG-4PGA0880-3C
4 980 F3SG-4PGA0980-4C
4 1,280 F3SG-4PGA1280-4C
Available soon
