F3SG-SR/PG
46
Floor Mount System
Floor Mount Column
Mirror Column (for F3SG-SR Safety Light Curtain)
Note: The F3SG-SR Safety Light Curtain with the protective height of 2280 or more cannot be used.
Mirror Column For Multiple Beam (for F3SG-PG Safety Multi-Light Beam)
Mount-Column Adjustable Base
Appearance
Protective height of safety light curtain
Column height Model
Safety light curtain Safety multi-light beam
Up to 0880 0580 990 mm F39-ST0990
Up to 1280 0880, 0980 1,310 mm F39-ST1310
Up to 1520 1280 1,630 mm F39-ST1630
Up to 1840 --- 1,950 mm F39-ST1950
Up to 2080 --- 2,270 mm F39-ST2270
Appearance Protective height of safety light curtain Column height Model
Up to 0800 990 mm F39-SML0990
Up to 1120 1,310 mm F39-SML1310
Up to 1440 1,630 mm F39-SML1630
Up to 1760 1,950 mm F39-SML1950
Up to 2080 2,270 mm F39-SML2270
Appearance Safety Multi-Light Beam Column height Model
F3SG-4PG0580-2@ 990 mm
F39-PML0990-2
F3SG-4PG0880-3A/3L
1,310 mm
F39-PML1310-3
F3SG-4PG0980-4@ F39-PML1310-4
F3SG-4PG1280-4@ 1,630 mm F39-PML1630-4
Appearance Application Model
Mounted to the floor mount column or mirror column.
The angle and height of the column can be adjusted.
F39-STB
Available soon
