Omron F3SG-SR Series User Manual

7
Easy line layout changes
Just replace the light curtain with the same protective height*
Even if the safety
distance changes, just
replace the light curtain
to ensure safety
Simply replace a light curtain using the same accessories because the F3SG-SR Series and F3SG-PG Series
share the same housing. There is no need to select and install accessories for a new light curtain.
Example : In order to secure a working space by installing the light curtain closer to the machine,
the perimeter guarding model is replaced with the finger protection model
* Except for some models and accessories.See page 37 and following for details.
F3SG-SR Series lineup
●
Standard model
○
Flexible height model (Increments of 40 mm)
F3SG-PG Series lineup
After replacement
Before replacement
Perimeter guarding
model
Finger protection
model
Same
brackets and
cables*
Protective height (mm)
160 200 240 280 320 360 400 440 480 520 560 580 600 640 680 720 760 800 840 880 920 960 980 1000 1040 112 0 1200 1280
Finger Protection
● ○ ● ○ ● ○ ● ○ ● ○ ● ○ ● ○ ○ ○ ● ○ ○ ○ ○ ● ●
Hand Protection
● ○ ● ○ ● ○ ● ○ ● ○ ● ○ ● ○ ● ○ ● ○ ● ○ ● ○ ● ● ● ●
Arm/Leg Protection
● ● ● ● ● ●
Body Protection
● ● ● ● ●
Protective height (mm)
160 200 240 280 320 360 400 440 480 520 560 580 600 640 680 720 760 800 840 880 920 960 980 1000 1040 112 0 1200 1280
Perimeter Access Guarding
● ● ● ●
Perimeter Guarding Long Range
● ● ● ●
Perimeter Guarding Deflect Mirror
● ● ● ●
Protective height (mm)
1360 1400 1440 1520 1600 1680 1760 1800 1840 1920 2000 2080 2280 2480
Finger Protection
● ● ● ●
Hand Protection
● ● ● ● ● ● ● ● ● ● ●
Arm/Leg Protection
●
Body Protection
