Omron F3SG-SR Series User Manual

F3SG-SR/PG
80
Mounted with Adjustable Side-Mount Brackets (Intermediate Brackets) (F39-LSGA)
Backside Mounting
250 max. 250 max. F
10
P
D
56.5
250 max. F 250 max.
C
56.5
4
56.5
<Screw: M5 or M6>
46.7
C(Protective height)
32
38
6.3
73
20
50
Adjustable
Side-Mount
Bracket
(F39-LSGA)
Adjustable
Side-Mount
Bracket
(F39-LSGA)
4
2-M5
or M6
2-M5
or M6
* The number of brackets required to mount either one of emitter and receiver.
Dimension C 4-digit number of the type name (Protective height: )
Dimension D
F3SG-SR-14
C-20
F3SG-SR-25
F3SG-SR-45
C-40
F3SG-SR-85
Dimension P
F3SG-SR-14 10
F3SG-SR-25 20
F3SG-SR-45 40
F3SG-SR-85 80
Protective height
(Dimension C)
Number of Adjustable
Side-Mount Bracket *
Dimension F
0160 to 0280 1 1000 mm max.
0320 to 1440 2 1000 mm max.
1520 to 2480 3 1000 mm max.
