1.1 Main Functions and Features of the K3HB-S
1-3
Outputs
Display
Other
Comparative output pattern Hysteresis Output refresh stop
The comparative output
pattern can be selected as
standard output, zone output,
and level output.
→ P.5-36
Prevents comparative output
chattering when the
measurement value fluctuates
slightly near the set value.
→ P.5-38
Holds the output status when
comparative results outputs
other than PASS turn ON.
→ P.5-44
PASS output change Output OFF delay Shot output
Comparative results other
than PASS and error signals
can be output from the PASS
output terminal.
→ P.5-49
Connects the comparative output
OFF timing for a set interval.
Comparative output ON times can
be held when comparative results
change quickly.
→ P.5-47
Produces a constant
comparative output ON time.
→ P.5-41
Output de-energization Startup compensation timer Output test
Reverses the output logic of
comparative outputs for
comparative results.
→ P.5-51
Constant-time measurements
can be stopped by an external
signal input.
→ P.5-21
Output operation can be
confirmed without actual input
signals, by setting test
measurement values using
the keys.
→ P.5-71
Display value selection Display color selection Display refresh period
The current display value can
be selected from the present
value, the maximum value,
and the minimum value.
→ P.5-62
The PV display color can be
set to either green or red. The
present value color can be
switched according to the
status of comparative outputs.
→ P.5-65
When inputs change quickly,
the display refresh period can
be delayed to reduce
flickering and make the
display easier to read.
→ P.5-60
Position meter Scaling Comparative set value display
Displays the current
measurement value as a position
in relation to the scaling width on
a meter with 20 sections.
→ P.5-67
Can convert the input signal to
any display value.
→ P.5-12
The comparative set value
can be set to not display
during operation.
→ P.5-64
Max/Min hold Bank selection Bank copy
Holds the maximum and
minimum measurement
values.
→ P.5-46
Eight comparative set value
banks can be selected using
the keys on the front of the
Unit or by external inputs.
Groups of comparative set
values can be set and can be
selected as groups.
→ P.5-72
Any bank setting can be
copied to all banks.
→ P.5-77
User calibration
The user can calibrate the
K3HB-S.
→ P.6-1
