Omron M1 Series User Manual

Power
supply
line
Standard applicable
motor (kW)
Inverter model Specifications Fuse rating (A)
Three-
phase 400
V
0.4 3G3M1-A4004 HHD 50 (IEC 60269-4)
0.75 HND
HD
ND
3G3M1-A4007 HHD 50 (IEC 60269-4)
1.1 HND
HD
1.5 ND
3G3M1-A4015 HHD 50 (IEC 60269-4)
2.2 HND
HD
ND
3G3M1-A4022 HHD 63 (IEC 60269-4)
3.0 HND
HD
ND
3G3M1-A4030 HHD 63 (IEC 60269-4)
4.0 HND
HD
ND
3G3M1-A4040 HHD 63 (IEC 60269-4)
5.5 HND
HD
ND
3G3M1-A4055 HHD 100 (IEC 60269-4)
7.5 HND
HD
3G3M1-A4075 HHD 100 (IEC 60269-4)
11 3G3M1-A4055 ND 100 (IEC 60269-4)
3G3M1-A4075 HND 100 (IEC 60269-4)
HD
3G3M1-A4110 HHD 125 (IEC 60269-4)
15 3G3M1-A4075 ND 100 (IEC 60269-4)
3G3M1-A4110 HND 125 (IEC 60269-4)
HD
3G3M1-A4150 HHD 160 (IEC 60269-4)
2 Design
2-65
M1 Series Standard Type User's Manual (I669)
2-4 Others
2
2-4-2 Compliance with EU Directives and UKCA

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
