Parame-
ter No.
Function name Data
Default
data
Unit
E44
Operator Display when
Stopped Selection
0: Specified value
1: Output value
0 -
In 2nd control, each of A60 and A61 are used for E50 and E39.
Parame-
ter No.
Function name Data
Default
data
Unit
E50
1st Frequency Conver-
sion Coefficient
0.01 to 600.00 30.00 -
A60
2nd Speed Conversion
Coefficient
0.00: Using E50 value
0.01 to 600.00
0.00 -
E39
Display Coefficient 1
for Transport Time /
Auxiliary Display Coef-
ficient 1 for Speed
Monitor
0.000 to 9999 1.000
-
A61
2nd Display Coefficient
for Transport time /
Auxiliary Display Coef-
ficient for Speed Moni-
tor
0.000 to 9999 1.000 -
A filter can be applied to the display of the operation status monitor of the output frequency, output
current and other information on the touch panel at Operator Display Filter (E42). When load fluctua-
tions, for example, cause variance in the monitor values making them difficult to see, set a larger val-
ue.
Parame-
ter No.
Function name Data
Default
data
Unit
E42 Operator Display Filter 0.0 to 5.0 s 0.5 -
Program Mode
The Program mode has functions, for example, for setting and checking parameters, and for monitor-
ing maintenance-related information and input/output (I/O) terminal information.
The digit (number) on the left end displayed on the Digital Operator LED indicates the menu No., and
the remaining three digits indicate menu content.
From the second time onwards that the Program mode is entered, the menu that was active when the
Program mode was previously exited is displayed.
3 Operation and Test Run
3-7
M1 Series Standard Type User's Manual (I669)
3-1 Operation of Operator
3
3-1-2 Key Operation Method
