Page #199 background imageLoading...
Page #199 background image
Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit
W32 PID Output Monitor
-150.00 to 150.00
0 - %
W33 Analog Input Monitor
-9990 to 0.00 to 9990
0 - -
W40 Input Terminal Monitor
Bit15: ---
Bit14: ---
Bit13: ---
Bit12: EN2
Bit11: EN1
Bit10: ---
Bit9: ---
Bit8: ---
Bit7: ---
Bit6: DI5
Bit5: DI4
Bit4: DI3
Bit3: DI2
Bit2: DI1
Bit1: DI7
Bit0: DI6
0 -
-
W41 Output Signal Monitor
Bit15: ---
Bit14: ---
Bit13: ---
Bit12: ---
Bit11: ---
Bit10: ---
Bit9: ---
Bit8: RO
Bit7: ---
Bit6: ---
Bit5: ---
Bit4: ---
Bit3: ---
Bit2: ---
Bit1: DO2
Bit0: DO1
0 -
-
4 Parameter List
4-33
M1 Series Standard Type User's Manual (I669)
4-1 List of Monitors by Group
4
4-1-2 Parameter W (Monitor 2)
