Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
F14
Power Interruption Re-
start Mode Selection
0: Immediately trip(Free run
stop)
1: Trip after a recovery from
power failure(Free run stop)
2: Trip after decelerate-to-stop
3: Continue to run
4: Restart at the frequency se-
lected by E152
6: Decelerate-to-stop(w/o trip)
1
A
vaila-
ble
-
page
7-49
F15
1st Frequency Upper
Limit
0.00 to 590.00 Hz
70.00
Availa-
ble
Hz
page
5-32
F16
1st Frequency Lower
Limit
0.00 to 590.00 Hz
0.00
Availa-
ble
Hz
page
5-32
F18
Input Terminal [AI1,
AI2] Bias for 1st Fre-
quency Command
-100.00 to 100.00 %
0.00
Availa-
ble
%
page
7-38
F20
1st DC Injection Brak-
ing Start Frequency
0.0 to 60.0 Hz
0.0
Availa-
ble
Hz
page
7-63
F21
1st DC Injection Brak-
ing Level
0 to 100% (HHD mode)
0 to 80% (HND/HD mode)
0 to 60% (ND mode)
Based on inverter rated cur-
rent
0
Availa-
ble
%
page
7-63
F22
1st DC Injection Brak-
ing T
ime
0.00: Disable
0.01 to 30.00 s
0.00
Availa-
ble
s
page
7-63
F23 1st Starting Frequency
0.0 to 60.0 Hz
0.5
Availa-
ble
Hz
page
7-114
F24
1st Starting Frequency
(Holding time)
0.00 to 10.00 s
0.00
Availa-
ble
s
page
7-1
14
4 Parameter List
4-80
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
