Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
C30
2nd Frequency Refer-
ence Selection
0: Operator (Up/Down keys)
(balancelessbumpless switch-
ing unavailable)
1: Analog voltage input (termi-
nal AI1)
2: Analog current input (termi-
nalAI2 (AII))
3: Analog voltage input (termi-
nal AI1) + analog current input
(terminal AI2 (AII))
5: Analog voltage input (termi-
nal AI2 (AIV))
7: UP/DWN control
8: Operator (UP and DOWN
keys) (balancelessbumpless
switching available)
10: Pattern operation/ timed
operation
12: Pulse train input
13: Calculation result
14: RS-485 communication
15: Fieldbus (Reserved)
2 - -
page
5-27
C31
Input Terminal [AI1]
Offset
-5.0 to 5.0 %
0.0
Availa-
ble
%
page
7-38
page
7-123
C32
Input Terminal [AI1]
Gain（Command）
0.00 to 400.00 %
100.00
Availa-
ble
%
page
7-38
page
7-123
C33
Input Terminal [AI1]
Filter
0.00 to 5.00 s
0.05
Availa-
ble
s
page
7-123
C34
Input Terminal [AI1]
Gain (Analog Input)
0.00 to 100.00 %
100.00
Availa-
ble
%
page
7-38
page
7-123
C35
Input Terminal [AI1]
Polarity Selection
0: Bipolar
1: Unipolar
1 - -
page
7-38
page
7-123
C36
Input Terminal [AI2]
Offset （AII
）
-5.0 to 5.0 %
0.0
Availa-
ble
%
page
7-38
page
7-123
4 Parameter List
4-109
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-3 Parameter C (Frequency Reference and Analog Input Functions)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
