Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
C54
Input Terminal [AI1,
AI2] Normal/Inverse
Operation for 2nd Fre-
quency Command
0: Normal
1: Inverse
0
Availa-
ble
-
page
7-44
C55
Input Terminal [AI1]
Bias (Command)
-200.00 to 200.00 %
0.00
Availa-
ble
%
page
7-38
page
7-123
C56
Input Terminal [AI1]
Bias (Analog Input)
0.00 to 100.00 %
0.00
Availa-
ble
%
page
7-38
C58 Do not use - - - - -
C59
Input Terminal [AI1]
Analog Input Adjust-
ment Maximum
Scale
-999.00 to 0.00 to 9,990.00
100 - -
page
7-123
C60
Input Terminal [AI1]
Analog Input Adjust-
ment Minimum Scale
-999.00 to 0.00 to 9,990.00
0 - -
page
7-38
page
7-123
C61
Input Terminal [AI2]
Bias (AII Command)
-200.00 to 200.00 %
0.00
Availa-
ble
%
page
7-38
page
7-123
C62
Input Terminal [AI2]
Bias (AII Analog Input)
0.00 to 100.00 %
0.00
Availa-
ble
%
page
7-38
C64 Do not use - - - - -
C65
Input Terminal [AI2]
Analog Input Adjust-
ment Maximum Scale
(AII)
-999.00 to 0.00 to 9990.00
100 - -
page
7-123
C66
Input Terminal [AI2]
Analog Input Adjust-
ment Minimum Scale
(AII)
-999.00 to 0.00 to 9990.00
0 - -
page
7-123
C67
Input Terminal [AI2]
Bias (AIV Command)
-200.00 to 200.00 %
0.00
Availa-
ble
%
page
7-38
page
7-123
C68
Input Terminal [AI2]
Bias (AIV Analog In-
put)
0.00 to 100.00 %
0.00
Availa-
ble
%
page
7-38
page
7-123
C70 Do not use - - - - -
4 Parameter List
4-111
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-3 Parameter C (Frequency Reference and Analog Input Functions)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
