[d209 bit 1] Direction of return-to-origin operation 0: Forward
rotation direction (+)
When origin position > origin limit
switch position
Startup di-
rection of
return-to-
origin oper-
ation [d209
bit 0]
Initial
posi-
tion
Return-to-origin pattern diagram
1: - direction
- side
from
origin
limit
switch
+OT
-OT
Origin LS
Origin
Direction of return-to-origin operation +
Startup direction of
return-to-origin operation -
+ side
from
origin
limit
switch
+OT-OT
Origin LS
Origin
Direction of return-to-origin operation +
Startup direction of
return-to-origin operation -
[d209 bit 1] Direction of return-to-origin operation 1: Reverse
rotation direction (+)
When origin position < origin limit
switch position
Startup di-
rection of
return-to-
origin oper-
ation [d209
bit 0]
Initial
posi-
tion
Return-to-origin pattern diagram
0: + direction
- side
from
origin
limit
switch
+OT-OT Origin LS
Direction of return-to-origin operation -
Startup direction of
return-to-origin operation +
Origin
+ side
from
origin
limit
switch
+OT
-OT
Origin LS
Origin
Direction of return-to-origin operation -
Startup direction of
return-to-origin operation +
6 Vector Control and Applied Functions
6-46
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
