Omron M1 Series User Manual

OFF
OFF
ON
ON
ONOFF
Output frequency
Output current
RUN command
Brake release signal
“BRK”
Brake confirmation signal
“BOK”
Vector control Operation time chart at startup
J95 = 0:
Brake control
Brake-release
Torque
Torque command
F24: 1st Starting
Frequency 1
Holding Time
F23: 1st Starting
Frequency
E181: Acceleration Wait Time on Brake Control
J68: Brake Control Brake-release Current
J70: Brake Control Brake-release Timer
H180: Brake Error Detection Time
6 Vector Control and Applied Functions
6-74
M1 Series Standard Type User's Manual (I669)
