Item No.
Parame-
ter No.
Item Range Display item
3_22 W26
Magnetic Flux Com-
mand Value
0 to 999 [%]
The flux command value is dis-
played in increments of 1%.
The magnetic flux command cal-
culated by vector control is dis-
played. 0 is displayed for other
than vector control.
In the case of an induction motor
(IM), the magnetic flux that is
generated when a current equiva-
lent to the no-load current flows is
displayed on the monitor as
100%.
In the case of a synchronous mo-
tor (PM), the magnetic flux equiv-
alent to the PM Motor Induced
Voltage (P63) is displayed on the
monitor as 100%.
3_23 M74
Running Status 2
Monitor
0000Hex to FFFFHex
The operation status is displayed
by a four-digit hexadecimal.
0000 to FFFF hex
Bit15: Motor type (1: PM motor /
0: Induction motor)
Bit14: During EN circuit diagnosis
Bit7: During speed control (1 dur-
ing control)
Bit5 Bit4: Select motor
00: 1st motor
01: 2nd motor
10: Reserved
11: Reserved
Bit3 to 0: Control method
0000: V/f control without slip
compensation
0001: Dynamic torque vector
control
0010: V/f control with slip com-
pensation
0011: V/f control with speed sen-
sor
0100: Dynamic torque vector
control with speed sensor
0101: V
ector control without
speed sensor
0110: Vector control with speed
sensor
0111: Torque control (Vector con-
trol without speed sensor)
1000: Torque control (Vector con-
trol with speed sensor)
3_25 - Reserved - -
3_29 W116 PG Feedback Value 0.00 to 590.0 [Hz]
The value obtained by converting
the PG feedback value to fre-
quency is displayed in Hz.
7 Other Functions
7-8
