Page #515 background image
Item
No.
Parameter
No.
Item Range Description
6_07 X66
Last Alarm Info. Cu-
mulative Ope. Time
0 to 655,350 hours
The number of operations of the motor
(number of times the RUN command for
the inverter is turned ON) is calculated
and displayed.
6_09 X68
Last Alarm Info. Main
Circuit DC Voltage
0.0 to 999.0 [V]
The Main Circuit DC Voltage of the inver-
ter is displayed.
6_30
X118
Last Alarm Info. Cu-
mulative Running
Time
0 to 655,350 hours
The cumulative time of the inverter RUN
state is displayed.
The cumulative operation time is dis-
played alternately in the upper digits and
lower digits.
When the lower three digits are dis-
played, an h (hours) is displayed in the
lowermost digit.
3 Second last alarm
6_00 Z00
Second Last Alarm
Info. Output Frequen-
cy
0.00 to 99.99,
100.0 to 590.0 [Hz]
The output frequency before slip com-
pensation is displayed in increments of
0.01 Hz. A value of 100.0 Hz or higher is
displayed in increments of 0.1 Hz.
6_01
Z01
Second Last Alarm
Info. Output Current
0.00 to 99.99,
100.0 to 655.3 [A]
The output current is displayed. A cur-
rent value of 100.0A or higher is dis-
played in increments of 0.1 A.
Display unit: A (Ampere)
6_06 Z05
Second Last Alarm
Info. Running Status
0000Hex to
FFFFHex
The operation status is displayed by a
four-digit hexadecimal.
6_07 Z06
Second Last Alarm
Info. Cumulative Ope.
T
ime
0 to 655,350 hours
The number of operations of the motor
(number of times the RUN command for
the inverter is turned ON) is calculated
and displayed.
6_09 Z08
Second Last Alarm
Info. Main Circuit DC
Voltage
0.0 to 999.0 [V]
The Main Circuit DC Voltage of the inver-
ter is displayed.
6_30
X128
Second last Alarm In-
fo. Cumulative Run-
ning Time
0 to 655,350 hours
The cumulative time of the inverter RUN
state is displayed.
The cumulative operation time is dis-
played alternately in the upper digits and
lower digits.
When the lower three digits are dis-
played, an h (hours) is displayed in the
lowermost digit.
4 Third last alarm
6_00 Z50
Third Last Alarm Info.
Output Frequency
0.00 to 99.99,
100.0 to 590.0 [Hz]
The output frequency before slip com-
pensation is displayed in increments of
0.01 Hz. A value of 100.0 Hz or higher is
displayed in increments of 0.1 Hz.
6_01
Z51
Third Last Alarm Info.
Output Current
0.00 to 99.99,
100.0 to 655.3 [A]
The output current is displayed. A cur-
rent value of 100.0A or higher is dis-
played in increments of 0.1 A.
Display unit: A (Ampere)
6_06 Z55
Third Last Alarm Info.
Running Status
0000Hex to
FFFFHex
The operation status is displayed by a
four-digit hexadecimal.
7 Other Functions
7-23
M1 Series Standard Type User's Manual (I669)
7-1 Status Monitors
7
7-1-4 Alarm information
