Page #611 background image
Parameter No. Function name Data
Default
data
Unit
E134 Frequency Addition Amount 0.00 to 590.0 0.00 Hz
E135
Frequency Addition Sign
Selection
0: Frequency command + E134
0 -
1: Frequency command - E134
E01 to E05,
E98, E99
Input Terminal [DI1] to [DI7]
Function Selection
161: ADD (Frequency addition) - -
Note 1. If the sign of the frequency reference changes (from (-) to (+), or from (+) to (-)) as a result of the calcula-
tion, the rotation direction is reversed.
Note 2. When the PID function is used, this function is enabled even for the PID target value.
The value is added in increments of 0.01% where the Frequency Addition Amount (E134) with respect to
the target PID value is taken to be 100%.
At this time, if a value larger than 100.0 is set, the limit is set at 100.0.
7-9-10
UP/DOWN control
Use this function to change the inverter output frequency via the multifunction input terminals UP and
DWN.
Parameter No. Function name Data
Default da-
ta
Unit
F01
C30
1st Frequency Reference
Selection
2nd Frequency Reference
Selection
7: UP/DOWN control 0 -
H61
UP/DOWN Control Initial
Value Selection
0: 0.00 Hz
1 -
1: Frequency reference when the RUN
command is turned OFF
E01 to E05, E98,
E99
Input T
erminal [DI1] to
[DI7] Function Selection
17: UP (UP/DWN function accelerat-
ed)
- -18: DWN (UP/DWN function decelerat-
ed)
58: UDC (UP/DWN function data clear)
7 Other Functions
7-119
M1 Series Standard Type User's Manual (I669)
7-9 Other Operation Functions
7
7-9-10 UP/DOWN control
