Parameter No. Function name Data
Default da-
ta
Unit
E43
Operator Display Selection
during Run
0 to 32
0: Speed monitor (Selectable with
E48)
3: Output current
4: Output voltage
8: Calculated torque
9: Input power
10: PID process command
12: PID feedback
13: Timer value
14: PID output
15: Load factor
16: Motor output
17: Analog signal input monitor
21: Current position
22: Position error
23: Torque current (%)
24: Magnetic flux command (%)
25: Input watt-hour
28: T
arget position
29: PID deviation
30: Torque bias
32: Reserved
0 -
E44
Operator Display when
Stopped Selection
0; 1
0: Specified value
1: Output value
0 -
E48
Operator Display Speed
Monitor Item Selection
0 to 7
0: Output frequency 1 (Before slip
compensation)
1: Output frequency 2 (After slip com-
pensation)
2: Reference frequency
3: Motor rotation speed
4: Load rotation speed
5: Feed speed
6: Transport time for specified length
7: Speed (%)
0 -
• When the power is ON, the parameter selected at Operator Display when Stopped Selection (E44)
is displayed. At the default setting, the output frequency (before slip compensation) is displayed, and
initial value “0.00” is displayed flashing. (Refer to 3-1-2 Key Operation Method on page 3-3
.)
•
When the RUN command is turned ON, the frequency reference when the previous RUN command
is OFF is output. T
o operate from 0 Hz when the RUN command is ON, set UP/DOWN Control Initial
Value Selection (H61) to 0.
• Commands from the UP and DWN terminals are enabled only when the RUN command is ON. The
frequency reference is added when the UP terminal is ON. The frequency reference is subtracted
when the DWN terminal is ON. Addition and subtraction of the frequency reference is stopped when
both are ON. When either of the terminals is OFF, the frequency reference is added or subtracted
according to the command from the ON terminal.
7 Other Functions
7-120
M1 Series Standard Type User's Manual (I669)
