Omron M1 Series User Manual

Power
system
Inverter type
Standby
power
Carrier frequency (Parameter No.F26 (Object 3004Hex-1BHex)
*1
ND HD HND HHD
Factory
shipment
value
Factory
shipment
value
Factory
shipment
value
Maxi-
mum set
value
Factory
shipment
value
Maxi-
mum set
value
Three-phase 200 V
3G3M1-
A2075
31 - - 440 540 280 360
3G3M1-
A2110
34 - -
520 700 440 540
3G3M1-
A2150
31 - - 640 810 520 700
3G3M1-
A2185
38 - - 770 970 660 860
Three-phase 400 V
3G3M1-
A4004
14 33 32 33 58 32 56
3G3M1-
A4007
14 57 50 57 110 50 93
3G3M1-
A4015
17 73 69 73 140 67 120
3G3M1-
A4022
17 98 95 98 180 79 145
3G3M1-
A4030
17 120 120 120 230 100 190
3G3M1-
A4040
17 155 150 150 265 130 240
3G3M1-
A4055
31 260 190 190 370 170 320
3G3M1-
A4075
31 380 290 290 510 220 390
3G3M1-
A41
10
31 460
390 390 630 300 490
3G3M1-
A4150
31 470 410 410 750 340 600
3G3M1-
A4185
31 710 510 510 870 440 770
3G3M1-
A4220
31 900 710 710 1000 510 900
2 Design
2-5
M1 Series Standard Type User's Manual (I669)
2-1 Installation
2
2-1-2 Installation Environment

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
