Power
system
Inverter type
Standby
power
Carrier frequency (Parameter No.F26 (Object 3004Hex-1BHex)
*1
ND HD HND HHD
Factory
shipment
value
Factory
shipment
value
Factory
shipment
value
Maxi-
mum set
value
Factory
shipment
value
Maxi-
mum set
value
Single-phase 200 V
3G3M1-
AB001
13 - - 19 21 17 20
3G3M1-
AB002
13 - - 29 31 23 27
3G3M1-
AB004
13 - - 47 50 36 40
3G3M1-
AB007
13 - - 66 69 55 59
3G3M1-
AB015
17 - - 94 110 78 100
3G3M1-
AB022
17 - - 115 140 100 130
3G3M1-
AB037
31 - - - - 165 230
*1. The inverter generating loss at rated output current.
The maximum set value (max. carrier) differs depending on specification.
2 Design
2-6
