Data Format [93]: Floating Point Data
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Exponent
part
Mantissa part
Exponent part: 0 to 3, Mantissa part: 0 to 9,999
Value represented in this format = Mantissa part × 10 to the power of (exponent part - 1)
Value Mantissa part Exponent part 10 to the power of (exponent part - 1)
0.0 to 999.9 0 to 9,999 0 0.1
1,000 to 9,999 1,000 to 9,999 1 1
10,000 to 99,990 1,000 to 9,999 2 10
100,000 to 999,900 1,000 to 9,999 3 100
Example: Integrated Power Monitor (W81) = 12,340
12,340 = Mantissa part: 1,234 (04D2 hex), Exponent part: 2 = C4D2 hex →
Example: Integrated Power Monitor (W81) = 567.8
567.8 = Mantissa part: 5,678 (162E hex), Exponent part: 0 = 162E hex →
Data Format of Inverter Parameters
Parameter
No.
MODBUS ad-
dress (MSB)
MODBUS ad-
dress (LSB)
Parameter name
Communica-
tion data for-
mat (during
single-word
access)
Communica-
tion data for-
mat (during
double-word
access)
F00 3000h -
Operator Protection Function
Selection
1 -
F01 3001h -
1st Frequency Reference Se-
lection
1 -
F02 1201h - 1st RUN Command Selection 1 -
F03 3003h -
1st Maximum Output Fre-
quency
3 -
F04 3004h - 1st Base Frequency 3 -
F05 3005h -
1st Rated Voltage at Base
Frequency
1 -
F06 3006h -
1st Rated Voltage at Maxi-
mum Output Frequency
1 -
F07 1102h 1103h 1st Acceleration Time 1 12 6
F08 1104h 1105h 1st Deceleration Time 1 12 6
F09 300Bh -
1st Manual Torque Boost Volt-
age
3 -
F10 300Ch -
1st Motor Electronic Thermal
Characteristic Selection
1 -
F11 300Dh -
1st Motor Electronic Thermal
Level
19 -
8 Communications Functions
8-47
M1 Series Standard Type User's Manual (I669)
8-9 Modbus Communication Data Lists
8
8-9-2 Register List
