Parameter

No.

MODBUS ad-

dress (MSB)

MODBUS ad-

dress (LSB)

Parameter name

Communica-

tion data for-

mat (during

single-word

access)

Communica-

tion data for-

mat (during

double-word

access)

d23 3FD7h -

Speed Deviation Error Proc-

essing Selection

1 -

d24 3FD8h - Zero Speed Control 1 -

d25 3FD9h -

Speed Control Speed Loop

Switching T

ime at Parameter

Change

7 -

d32 3FE0h

3FE1h Speed Limit 1 in Forward 1 1

d33 3FE2h 3FE3h Speed Limit 2 in Reverse 1 1

d35 3FE5h - Over Speed Detection Level 1 -

d41 3FEBh - Special Control Selection 1 -

d51 3FF5h - Reserved 2 -

d52 3FF6h - Reserved 2 -

d55 3FF9h - Reserved 1 -

d59 3FFDh - Reserved 1 -

d60 3FFEh - Reserved 1 -

d61 3FFFh - Reserved 7 -

d62 4000h - Reserved 1 -

d63 4001h - Reserved 1 -

d67 4005h -

Motor Starting Mode Auto

Search in Speed Sensor less

ector Control

1 -

d68 4006h -

Reserved 3 -

d70 4008h -

Speed Control Slip Frequency

Limit

5 -

d71 4009h - Reserved 5 -

d72 400Ah - Reserved 5 -

d73 400Bh - Reserved 1 -

d74 400Ch - Reserved 1 -

d75 400Dh - Reserved 5 -

d76 400Eh - Reserved 1 -

d77 400Fh - Reserved 1 -

d78 4010h - Reserved 1 -

d79 4011h - Reserved 1 -

d80 4012h -

1st PM Motor Magnetic Pole

Position Pull-in Frequency

3 -

d81 4013h - Reserved 1 -

d82 4014h -

Magnetic Flux Weakening

Control Function Selection

1 -

d83 4015h -

Magnetic Flux Weakening

Lower Limit

1 -

d84 4016h - Reserved 1 -

d85 4017h - Reserved 1 -

d86 4018h -

Acc/Dec Output Frequency

Filter

7 -

d88 401Ah - Reserved 5 -

8 Communications Functions

8-71

M1 Series Standard Type User's Manual (I669)

8-9 Modbus Communication Data Lists

8-9-2 Register List
