Parameter

No.

MODBUS ad-

dress (MSB)

MODBUS ad-

dress (LSB)

Parameter name

Communica-

tion data for-

mat (during

single-word

access)

Communica-

tion data for-

mat (during

double-word

access)

d224 4158h -

Detection Level of Excessive

Positioning Deviation (LSB)

1 -

d225 4159h -

Software Overtravel Detection

Position in the Positive Direc-

tion (MSB)

2 -

d226 415Ah -

Software Overtravel Detection

Position in the Positive Direc-

tion (LSB)

1 -

d227 415Bh -

Software Overtravel Detection

Position in the Negative Direc-

tion (MSB)

2 -

d228 415Ch -

Software Overtravel Detection

Position in the Negative Direc-

tion (LSB)

1 -

d237 4165h - Positioning Data Type 1 -

d238 4166h -

Position Data Determination

ime

7 -

d239

4167h -

Positioning Completed Range 1 -

d240 165Fh - Preset Position (MSB) 2 -

d241 1660h - Preset Position (LSB) 1 -

d242 416Ah - Homing Offset (MSB) 1 -

d243 416Bh - Homing Offset (LSB) 1 -

d244 163Dh - Positioning Data 1 (MSB) 2 -

d245 163Eh - Positioning Data 1 (LSB) 1 -

d246 163Fh - Positioning Data 2 (MSB) 2 -

d247 1640h - Positioning Data 2 (LSB) 1 -

d248 1641h - Positioning Data 3 (MSB) 2 -

d249 1642h - Positioning Data 3 (LSB) 1 -

d250 1643h - Positioning Data 4 (MSB) 2 -

d251 1644h - Positioning Data 4 (LSB) 1 -

d252 1645h - Positioning Data 5 (MSB) 2 -

d253 1646h - Positioning Data 5 (LSB) 1 -

d254 1647h - Positioning Data 6 (MSB) 2 -

d255 1648h - Positioning Data 6 (LSB) 1 -

d256 1649h - Positioning Data 7 (MSB) 2 -

d257 164Ah - Positioning Data 7 (LSB) 1 -

d258 164Bh - Positioning Data 8 (MSB) 2 -

d259 164Ch - Positioning Data 8 (LSB) 1 -

d277 418Dh -

Positioning Data Setting Se-

lection via communication

1 -

d278 418Eh -

Restarting Positioning Range

Setting

1 -

d280 4190h -

Over Travel Forced Stop Op-

eration Selection

1 -

8 Communications Functions

8-73

M1 Series Standard Type User's Manual (I669)

8-9 Modbus Communication Data Lists

8-9-2 Register List
