29
OS32C
User’s Manual
Chapter2
Operating States & Output Modes
E
Fig. 2-12 Zone A extension.
The extension of the safety distance around the entire protection zone will guarantee the safe
operation of the scanner. However, most installations may benefit from using the smallest possible
monitoring zone perimeter to maximize usable work space. For other measures, refer to Additional
Zone Set Switching Strategies on page 137.
Zone set A Extension
Zone set A
Zone set B
Z
extra
S
Danger Area
of Zone set A
OS32C
