Appendix B
Device Protocol (MCW151-DRT-E only)
Object Mounting
Identity Object (0x01)
General data Compatible DeviceNet
specifications
Volume I-Release 1.3
Volume II-Release 1.3
---
Vendor name OMRON Corporation Vendor ID = 47
Device profile name Slave: Generic Profile number = 00
Product catalog number I203 ---
Product revision 3.2 ---
Physical conformance
data
Network current consumption 30 mA max. at 24 VDC ---
Physical layer insulation Yes ---
Supported LEDs Module Network ---
MAC ID setting DIP switch ---
Default MAC ID 0 ---
Baud rate setting DIP switch ---
Supported baud rates 125 kbps, 250 kbps and 500 kbps ---
Communications data Predefined Master/Slave
connection set
Group 2 only server ---
Dynamic connection support
(UCMM)
No ---
Explicit message fragmentation
support
Yes -- -
Object class Attribute Not supported
Service Not supported
Item ID content Get
(read)
Set
(write)
Value
Object instance Attribute 1 Vendor Yes No 47
2 Product Type Yes No 0
3 Product Code Yes No 900
4 Revision Yes No 3.2
5 Status (bits supported) Yes No bit 0 only
6 Serial number Yes No Unique for each Unit
7 Product name Yes No R88A-MCW151-
DRT-E
8 State Yes No ---
Item DeviceNet service Parameter option
Object instance Service 05 Reset No
0E Get_Attribute_Single
