3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-48
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
Variable name _EIP2_TagAdrErr
Meaning CIP Communications2 Tag Name Resolution
Error
Global/local Global
Function Indicates that tag resolution for CIP communications 2 failed (i.e., the address could not be identified from the tag name).
TRUE: Tag resolution failed (i.e., the address could not be identified from the tag name). The following causes are
possible.
•The size of the network variable is different from the tag settings.
•The I/O direction that is set in the tag data link settings does not agree with the I/O direction of the vari-
able in the CPU Unit.
•There is no network variable in the CPU Unit that corresponds to the tag setting.
FALSE: Other than the above.
Note You can use this system-defined variable only for the NX701 CPU Units.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related
instructions
---
Variable name _EIP_MultiSwONErr
Meaning Multiple Switches ON Error Global/local Global
Function NX-series CPU Units: Indicates that more than one switch turned ON at the same time in CIP communications 1.
TRUE: More than one data link start/stop switch changed to TRUE at the same time.
FALSE: Other than the above.
NJ-series CPU Units: Indicates that more than one switch turned ON at the same time.
TRUE: More than one data link start/stop switch changed to TRUE at the same time.
FALSE: Other than the above.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related
instructions
---
Variable name _EIP1_MultiSwONErr
Meaning CIP Communications1 Multiple Switches ON
Error
Global/local Global
Function Indicates that more than one switch turned ON at the same time in CIP communications 1.
TRUE: More than one data link start/stop switch changed to TRUE at the same time.
FALSE: Other than the above.
Note You can use this system-defined variable only for NX-series CPU Units.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related
instructions
---
Variable name _EIP2_MultiSwONErr
Meaning CIP Communications2 Multiple Switches ON
Error
Global/local Global
Function Indicates that more than one switch turned ON at the same time in CIP communications 2.
TRUE: More than one data link start/stop switch changed to TRUE at the same time.
FALSE: Other than the above.
Note You can use this system-defined variable only for the NX701 CPU Units.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related
instructions
---
To Next Page
