3-49
3 System-defined Variables Related to the Built-in EtherNet/IP Port
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
3-3 Specifications for Individual System-defined
Variables
3
Functional Classification: EtherNet/IP Communications Status
Variable name _EIP_TcpAppCfgErr
Meaning TCP Application Setting Error Global/local Global
Function TRUE: At least one of the set values for a TCP application (FTP, NTP, SNMP) is incorrect. Or, a read operation
failed.
FALSE: Normal.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related
instructions
---
Variable name _EIP_NTPSrvErr
Meaning NTP Server Connection Error Global/local Global
Function TRUE: The NTP client failed to connect to the server (timeout).
FALSE: NTP is not set or the connection was successful.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related
instructions
---
Variable name _EIP_DNSSrvErr
Meaning DNS Server Connection Error Global/local Global
Function TRUE: The DNS client failed to connect to the server (timeout).
FALSE: DNS is not enabled. Or, DNS is enabled and the connection was successful.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related
instructions
---
Variable name _EIP_EtnOnlineSta
Meaning Online Global/local Global
Function NX-series CPU Units: Indicates that the built-in EtherNet/IP port’s communications can be used via the communications
port 1 (that is, the link is ON, IP address is defined, and there are no errors).
TRUE: The built-in EtherNet/IP port’s communications can be used.
FALSE: The built-in EtherNet/IP port’s communications is disabled due to an error in initial processing, restart pro-
cessing, or link OFF status.
NJ-series CPU Units: Indicates that the built-in EtherNet/IP port’s communications can be used via the communications
port (that is, the link is ON, IP address is defined, and there are no errors).
TRUE: The built-in EtherNet/IP port’s communications can be used.
FALSE: The built-in EtherNet/IP port’s communications is disabled due to an error in initial processing, restart pro-
cessing, or link OFF status.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related
instructions
---
To Next Page
