Omron Sysmac NJ-series User Manual

5-3
5 Sysmac Studio Settings for the Built-in EtherNet/IP Port
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
5-1 TCP/IP Settings Display
5
*2 Refer to 4-2 Built-in EtherNet/IP Port IP Address Settings for details on setting IP addresses.
Precautions for Correct UsePrecautions for Correct Use
For an NX701 CPU Unit, you cannot set IP addresses that make two built-in EtherNet/IP ports
belong to the same network.
 IP Address (NJ-series CPU Unit)
*1 Refer to 4-2 Built-in EtherNet/IP Port IP Address Settings for details on setting IP addresses.
*2 These settings are required if you set IP address setting method to Fixed setting.
*3 This setting is valid if you set IP address setting method to Fixed setting.
 DNS
*1 These settings are required when DNS is used.
 Host Name - IP Address
Setting Description Default
IP address setting
method
Select one of the following IP address setting methods for
the built-in EtherNet/IP port.
*1
• Fixed setting
• Obtain from BOOTP server.
• Fix at the IP address obtained from BOOTP server.
Fixed setting
IP address
*2
Set the IP address for the built-in EtherNet/IP port. 192.168.250.1
Subnet mask
*2
Set the subnet mask for the built-in EtherNet/IP port. 255.255.255.0
Default gateway
*3
Set the IP address of the default gateway for the built-in
EtherNet/IP port. This setting is not required when the
default gateway is not used.
When the IP address settings are obtained from a BOOTP
server, the default gateway set in this item is disabled.
None
Setting Description Default
DNS Enable using DNS if a DNS is used to resolve host names
when host names are specified for the remote communica-
tions nodes in CIP communications and socket instructions.
A DNS server is required to use DNS.
Do not use.
Priority DNS server
*1
Set the IP address of the DNS server. You can set priority
and secondary IP addresses.
None
Secondary DNS server None
Domain name
*1
Sets the domain name of the domain to which the built-in
EtherNet/IP port belongs. (Single-byte alphanumeric char-
acters, dots, and hyphens: 48 characters max.)
None
Setting Description Default
Host Name Addresses are converted according to this setting when
host names are used to specify remote communications
nodes.
They can be set even if DNS is not used. You can set up to
six host names. (You can use up to 200 single-byte alpha-
numeric characters, dots, and hyphens with up to 63 single-
byte alphanumeric characters between dots.)
None
IP Address Set the IP addresses of the registered hosts. None
