5 Sysmac Studio Settings for the Built-in EtherNet/IP Port
5-4
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
 Keep Alive
 Default Gateway (NX-series CPU Unit)
*1 When the IP address setting method is set to Obtain from BOOTP server or the Fix at the IP address obtained
from BOOTP server, the default gateway obtained from a BOOTP server is enabled.
*2 For an NX701 CPU Unit, even if you are using both of port 1 and port 2, you can only set the default gateway
for one of the ports.
 IP Router Table
Setting Description Default
Keep Alive Set whether to use the remote node keep alive function of
connected servers and clients (such as socket services,
FTP server, Sysmac Studio, and FINS/TCP) for each con-
nection number. If the keep-alive function is used and the
remote node does not respond during the set keep-alive
monitoring time, the connection is disconnected. The con-
nection is left open if the power supply to the remote node
is turned OFF without warning. Use the keep-alive function
whenever possible.
• Use.
• Do not use.
Use.
Keep Alive Monitoring
Time
The connection is disconnected if the keep-alive function is
used and the remote node does not respond during the
monitoring time set in the Keep Alive Monitoring Setting.
Setting range: 1 to 65,535 (seconds)
300
Linger option Set whether to specify the Linger Option for connections to
FINS/TCP or socket services. If the Linger Option is speci-
fied, the port number is immediately opened even before
the port number is released after the socket closes (approx.
1 minute).
• Specify.
• Do not specify.
Do not specify.
Setting Description Default
Default gateway
*1
Set the IP address of the default gateway for the built-in
EtherNet/IP port. This setting is not required when the
default gateway is not used.
*2
When the IP address settings are obtained from a BOOTP
server, the default gateway set in this item is disabled.
None
Parameter Description Default
Destination IP address Set these settings when the built-in EtherNet/IP port is used
for tag data links or CIP message communications with
nodes on other IP network segments via an IP router. Also
set these settings to use an NX-series CPU Unit as an IP
router using the IP routing function of the built-in Ether-
Net/IP port.
You can set up to 256 combinations of IP addresses and
gateway addresses with an NX701 CPU Unit, and up to
eight combinations with an NJ-series CPU Unit and the
NX1P2 CPU Unit.
Specify 0 for the host portions of the IP addresses.
None
Destination mask IP
address
Gateway address None
