7 Tag Data Link Functions
7-62
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
Clicking the No Button:
Performing a Batch Upload over the Network
Parameters are uploaded from all devices on the network. The current Network Configuration
Information will be lost.
The following dialog box will be displayed. Select the devices for which to upload parameters
and click the OK Button.
Clicking the Cancel Button:
The upload operation is cancelled. The upload is not performed.
4 If you click the No Button in step 2, the following dialog box is displayed.
Select the devices for which to upload parameters and click the OK Button.
