Versions
24
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
The functions that are supported depend on the unit version of the NJ/NX-series CPU Unit. The version
of Sysmac Studio that supports the functions that were added for an upgrade is also required to use
those functions.
Refer to the NJ/NX-series CPU Unit Software User’s Manual (Cat. No. W501) for the relationship
between the unit versions of the CPU Units and the Sysmac Studio versions, and for the functions that
are supported by each unit version.
When you set tag data links for the built-in EtherNet/IP port on an NJ/NX-series CPU Unit, use the ver-
sions of the Network Configurator and the Sysmac Studio that are given in the following table.
Unit Versions of CPU Units and Sysmac Studio Versions
Unit Versions of CPU Units and Peripheral Tool Versions
CPU Unit Network Configurator for EtherNet/IP Sysmac Studio
Model Version
Version
3.3x or
lower
Version
3.40
Version
3.50 or
3.51
Version
3.53 to
3.58
Version
3.59 to
3.60
Version
3.61 or
higher
Version
1.09 or
lower
Version
1.10 to
1.12
Version
1.13 to
1.16
Version
1.17 or
higher
NJ501-

Version 1.00
to 1.02
NA OK OK OK OK OK NA OK OK OK
NJ301-

Version 1.01
or 1.02
NA NA OK OK OK OK NA OK OK OK
NJ501-

NJ301-

Version 1.03
or later
NA NA NA OK OK OK NA OK OK OK
NJ101-

NX701-

Version 1.10
or later
NA NA NA NA OK OK NA NA OK OK
NX1P2-

Version 1.13
or later
NA NA NA NA NA OK NA NA NA OK
