8 CIP Message Communications
8-48
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
The attribute ID specifies the information to read.
 Class Attribute ID
The class attribute ID specifies the attribute of the entire object.
 Instance Attribute ID
The instance attribute ID specifies the attribute of the instance.
(1) Product Codes for Each Model
(2) Major and Minor CIP Revisions
Attribute ID
Attribute ID Parameter name Description Attribute
Read data
Data
type
Value
01 hex Revision Revision of the object Read UINT 0001 hex
02 hex Max Instance The maximum instance number Read UINT 0001 hex
Attribute ID Parameter name Description Attribute
Read data
Data
type
Value
01 hex Vendor ID Vendor ID Read UINT 002F hex
02 hex Device Type Device type Read UINT 000C hex
03 hex Product Code Product code Read UINT Refer to (1) Product Codes for
Each Model, below
04 hex Revision Device revision Read Struct ---
Major Revision Major revision Read USINT Refer to (2) Major and Minor CIP
Revisions, below
Minor Revision Minor revision Read USINT
05 hex Status Status of the built-in EtherNet/IP
port
Read WORD Refer to (3) Status Details of the
Built-in EtherNet/IP Port, below
06 hex Serial Number Serial number Read UDINT Set value
07 hex Product Name Product name Read STRING Set value
Model Product Code
NX701- 067D hex
NX1P2- 068B hex
NJ501-13 0665 hex
NJ501-14 0666 hex
NJ501-15 0667 hex
NJ301-11 066B hex
NJ301-12 066C hex
NJ101- 0680 hex
Unit version
CIP revisions
Major revision Minor revision
Unit version 1.00 01 hex 01 hex
Unit version 1.01 or 1.02 03 hex
Unit version 1.03 to 1.08 02 hex 01 hex
Unit version 1.09 02 hex
Unit version 1.10 03 hex
Unit version 1.11 or 1.12 04 hex
Unit version 1.13 or later 05 hex
