13-7
13 SNMP Agent
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
13-1 SNMP Agent
13
13-1-4 MIB Specifications
ifTable (2) NA
Interface entity table
---
ifEntry (1) NA
Row data for interface information
The index is ifIndex.
---
ifIndex (1) RO
A number used to identify the interface.
Sup-
ported.
• NX701 CPU Unit: 1
to 3
• NX1P2 CPU Unit:
1 to 2
• NJ-series CPU
Unit: 1 to 2
ifDescr (2) RO
Information related to the interface (includes man-
ufacturer name, product name, and hardware
interface version).
Sup-
ported.
• NX701 CPU Unit:
10/100/1000M
Gigabit Ethernet
Port
• NX1P2 CPU Unit:
10/100M Fast
Ethernet Port
• NJ-series CPU
Unit: 10/100M Fast
Ethernet Port
ifType (3) RO
The type of interface classified according to the
physical/link layer protocol directly under the net-
work layer of the protocol stack.
Sup-
ported.
ethernet-csmacd(6)
ifMtu (4) RO
MTU value
The maximum size (in octets) of datagrams that
can be sent and received through this interface.
Sup-
ported.
1,500
ifSpeed (5) RO
Estimated bandwidth
If a stable, accurate value cannot be obtained for
the bandwidth, a nominal value is set instead.
Sup-
ported.
• NX701 CPU Unit:
10000000/
100000000/
1000000000
• NX1P2 CPU Unit:
10000000/
100000000
• NJ-series CPU
Unit:
10000000/
100000000
ifPhysAddress (6) RO
MAC address
The physical address under the network layer of
the interface.
Sup-
ported.
The MAC address of
the EtherNet/IP port.
ifAdminStatus (7) RW
The preferred status of the interface.
You cannot send normal packets in the testing state.
up(1)
down(2)
testing(3)
Sup-
ported.
According to the
standard.
ifOperStatus (8) RO
The current status of the interface.
You cannot send normal packets in the testing state.
up(1)
down(2)
testing(3)
Sup-
ported.
According to the
standard.
Subtree name Standard [(identifier) attribute] Support
Implementation
specifications
