13 SNMP Agent
13-10
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
Ip Group: Ip
Subtree name Standard [(identifier) attribute] Support
Implementation
specifications
ipForwarding (1) RW
Indicates if the device operates as a gateway. IP
gateways can transfer datagrams, but IP hosts
can perform only source routing. Some nodes
take only one of these values. Therefore, if you
attempt to change this object from the SNMP
Manager, a badValue error is returned.
Forwarding (1)
Not-forwarding (2)
Sup-
ported.
• NX701 CPU Unit:
Forwarding(1)
• NX1P2 CPU Unit:
Not-forwarding (2)
• NJ-series CPU
Unit: Not-forward-
ing (2)
IpDefaultTTL (2) RW
The default value set for the IP header TTL if no
TTL value was given by the transport layer proto-
col.
Sup-
ported.
64
IpInReceives (3) RO
The number of all IP datagrams that reached the
interface, including errors.
Sup-
ported.
According to the
standard.
IpInHdrErrors (4) RO
The number of received datagrams that were dis-
carded because of an IP header error (checksum
error, version number error, format error, TTL
error, IP option error, etc.).
Sup-
ported.
According to the
standard.
IpInAddrErrors (5) RO
The number of packets that were discarded
because the destination address in the IP header
was not valid.
Sup-
ported.
According to the
standard.
ipForwDatagrams (6) RO
The number of IP datagrams that were transferred
to their final destination. If this node does not
operate as an IP gateway, this is the number of
datagrams that were successfully transferred
through source routing.
Sup-
ported.
According to the
standard.
ipInUnknownProtos (7) RO
The number of IP datagrams that were received
but discarded because they were of an unsup-
ported or unrecognized protocol.
Sup-
ported.
According to the
standard.
ipInDiscards (8) RO
The number of IP datagrams that could have con-
tinued to be processed without any problems, but
were discarded (for example, because of insuffi-
cient buffer space).
Sup-
ported.
According to the
standard.
ipInDelivers (9) RO
The number of datagrams delivered to an IP user
protocol (any higher level protocol, including
ICMP).
Sup-
ported.
According to the
standard.
ipOutRequests (10) RO
The number of times a send request was made for
an IP datagram by a local IP user protocol (any
higher level protocol, including ICMP). This
counter does not include ipForwDatagrams.
Sup-
ported.
According to the
standard.
ip
OutDisca
rds (11) RO
The number of IP datagrams that could have been
sent without any problems, but were discarded
(for example, because of insufficient buffer
space).
Sup-
ported.
According to the
standard.
