1-3-2 Part Names and Functions
 NJ-series CPU Unit
Ethernet Address Notation
A specific Ethernet address is allocated to each device connected to the Ethernet network. The
built-in EtherNet/IP port’s address is listed in 12-digit hexadecimal in the two places shown below on
the CPU Unit.
Indicators
Built-in EtherCAT port
Built-in EtherNet/IP port
USB port
Ethernet address (12 digits)
NJ501-XXXX
PORT1 : XXXXXXXXXXXX
PORT2 : XXXXXXXXXXXX
XXXXXXX XXXX
Ver. XXX
PORT 1
XXXXXX
XXXXXX
Upper 6 digits of Ethernet address
Lower 6 digits of Ethernet address
