Omron Sysmac NJ-series

15 Troubleshooting
15-48
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
*1 This applies to an NJ-series CPU Unit.
*2 This applies to an NX-series CPU Unit.
*1 This applies to an NJ-series CPU Unit.
*2 This applies to an NX-series CPU Unit.
Event name Restarting Ethernet Port Event code 9406 0000 hex
Meaning The built-in EtherNet/IP port was restarted.
Source EtherNet/IP Function Module Source details Communications
port,
*1
communi-
cations port 1,
*2
or Communica-
tions port 2
*2
Detection
timing
At user operation
Error attributes Level Information Recovery --- Log category Access
Effects User program Continues. Operation Not affected.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
--- --- ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The built-in EtherNet/IP port was
restarted.
--- ---
Attached
information
None
Precautions/
Remarks
None
Event name Tag Data Link All Run Event code 94070000 hex
Meaning Tag data link connections to all nodes have been established.
Source EtherNet/IP Function Module Source details
CIP,
*1
CIP1,
*2
or
CIP2
*2
Detection
timing
When establish-
ing tag data link
connection
Error attributes Level Information Recovery --- Log category System
Effects User program Continues. Operation Not affected.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
Lights. --- ---
System-defined
variables
Variable Data type Name
_EIP_TDLinkAllRunSta
*1
BOOL All Tag Data Link Communications
Status
_EIP1_TDLinkAllRunSta
*2
BOOL CIP Communications1 All Tag Data
Link Communications Status
_EIP2_TDLinkAllRunSta
*2
BOOL CIP Communications2 All Tag Data
Link Communications Status
Cause and
correction
Assumed cause Correction Prevention
Tag data link connections to all target
nodes have been established.
--- ---
Attached
information
None
Precautions/
Remarks
None
