15 Troubleshooting
15-62
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
01 0205 Error code returned from target:
There was a parameter error in the
frame used to open the connection.
This error does not
occur.
Depends on the tar-
get’s specifications.
(Contact the target
device’s manufacturer.)
Depends on the origi-
nator’s specifications.
(Contact the originator
device’s manufacturer.)
01 0302 Error code generated by originator
or returned from target:
The tag data link’s allowable band-
width (pps) was exceeded.
Check the connec-
tion settings (number
of connections and
RPI) at the origina-
tor and target.
Check the target’s con-
nection settings (num-
ber of connections and
RPI). Check the con-
nection settings (num-
ber of connections and
RPI) at the originator
and target.
Check the connection
settings (number of
connections and RPI)
at the originator and
target.
01 0311 Error code returned from target:
There was a parameter error in the
frame used to open the connection.
This error does not
occur.
Depends on the tar-
get’s specifications.
(Contact the target
device’s manufacturer.)
Depends on the origi-
nator’s specifications.
(Contact the originator
device’s manufacturer.)
01 0312 Error code returned from target:
There was a parameter error in the
frame used to open the connection.
This error does not
occur.
Depends on the tar-
get’s specifications.
(Contact the target
device’s manufacturer.)
Depends on the origi-
nator’s specifications.
(Contact the originator
device’s manufacturer.)
01 0315 Error code returned from target:
There was a parameter error in the
frame used to open the connection.
This error does not
occur.
Depends on the tar-
get’s specifications.
(Contact the target
device’s manufacturer.)
Depends on the origi-
nator’s specifications.
(Contact the originator
device’s manufacturer.)
01 0316 Error code returned from target:
There was a parameter error in the
frame used to close the connection.
This error does not
occur.
Depends on the tar-
get’s specifications.
(Contact the target
device’s manufacturer.)
Depends on the origi-
nator’s specifications.
(Contact the originator
device’s manufacturer.)
01 031C Error code generated by originator:
Some other error occurred.
This error does not
occur.
The originator gener-
ates this code when an
unsupported response
code is returned from
the target in reply to an
open request.
Depends on the origi-
nator’s specifications.
(Contact the originator
device’s manufacturer.)
08 --- Error code returned from target:
There is no Forward Open or Large
Forward Open service in the target
device.
This error does not
occur.
Depends on the tar-
get’s specifications.
(Contact the target
device’s manufacturer.)
Depends on the origi-
nator’s specifications.
(Contact the originator
device’s manufacturer.)
D0 0001 Error code generated by originator:
The connection operation is
stopped.
The connection was
stopped becau
se the
T
ag Data Link Stop
Bit was turned ON,
or the settings data
is being downloaded.
Either turn ON the
Tag Data Link Start
Switch, or wait until
the settings data has
been downloaded.
This code includes
fatal Controller errors
and Unit failure. To
handle these errors,
refer to 15-1-1 How
to Check for Errors.
The meaning of this
error code is defined by
each vendor, so it
depends on the target’s
specifications. (Con-
tact the target device’s
manufacturer.)
Depends on the origi-
nator’s specifications.
(Contact the originator
device’s manufacturer.)
D0 0002 Error code generated by originator:
The connection is being opened
(opening processing in progress).
Wait until the open-
ing processing is
completed.
The meaning of this
error code is defined by
each vendor, so it
depends on the target’s
specifications. (Con-
tact the target device’s
manufacturer.)
Depends on the origi-
nator’s specifications.
(Contact the originator
device’s manufacturer.)
Connection status
Source of error
Handling
General
Status
(hex)
Additional
Status
(hex)
Configuration 1 Configuration 2 Configuration 3
